Diomede MODULO-A 4.5W
Rectangle Surface Step Light
The Modulo A is an IP rated compact path light ideal for both indoor and outdoor applications.
A marine grade aluminium alloy housing treated with polyester powder coating makes the Modulo A family suitable for installation in the most harsh environments. The anodised aluminium reflector in silver or optional specular brass also gives to the Modulo an innovative and modern look. This versatile wall light offer a range or IP rated or Non IP rated remote drivers that can be easily integrated in any home or professional automation systems. Premium Quality, Italian Made product.
- Material Specifications
- MaterialAluminium Die-Cast Housing
- FinishPowder Polyester Coated
- Ingress ProtectionIP65
- Dimensions180mm(L) x 15mm(W) x 100(H)
- MountingWall Mounted, Surface
- Warranty5 Year Replacement
- Electrical Specifications
- Power SupplySupplied Seperately
- Input Voltage24V
- Optic Specifications
- Delivered Lumens195lm
- CRI80Ra
- Reported L70 (Hours)> 54,000 Hrs
- 900611012 MODULO A 4.5W Rectangle Surface Step Light, Solid White, 3000K, 195lm
- 900611013 MODULO A 4.5W Rectangle Surface Step Light, Ibiza Sand, 3000K, 195lm
- 900611014 MODULO A 4.5W Rectangle Surface Step Light, Meteor Grey, 3000K, 195lm
- 900611015 MODULO A 4.5W Rectangle Surface Step Light, Timeless Aluminium, 3000K, 195lm
Data Sheet
