ZORIN 100W
Premium Floodlight
The ZORIN LED Floodlight range is built to perform in demanding outdoor environments. Featuring robust die-cast aluminium construction with corrosion-resistant powder coating, it delivers reliable, long-lasting operation with minimal maintenance. The precision-adjustable bracket allows flexible installation and easy aiming to suit a wide range of applications. With a high-efficiency LED light source and multiple beam angle options, the ZORIN Floodlight provides powerful, uniform illumination wherever it’s needed. Available in a variety of wattages and dimming options, and backed by a 7-year warranty, it’s a dependable choice for commercial and industrial lighting projects.
- Material Specifications
- HousingAluminium Die-casting Body, with 316 stainless steel screws
- FinishAkzoNobel Powder Coat
- ColourBlack or Grey
- BenefitsCorrosion Resistant, Smooth Self-Cleaning Housing
- Dimensions379mm(L) x 278mm(W) x 55mm (H)
- Ingress ProtectionIP66
- Impact RatingIK08
- Weight4.1Kg
- Warranty7 Year Replacement
- Electrical Specifications
- Power SupplyIsolated Flicker-Free Driver
- DimmingNon-Dim (Standard), DALI-2 or 0-10V Available
- Input VoltageAC 100-240V
- System Watts98-103W
- Power Factor>0.95
- Operating Temperature (Ta)-20°C to +50°C
- Protection10KV Surge Protection
- Optic Specifications
- Light SourceLightning 5050 SMD LED Chips
- HousingTempered Glass Lens
- Delivered Lumens16,500lm (4000K)
- EfficacyUp to 160lm/W
- CRI>70
Variations
- ZRN100-3K-90-B ZORIN 100W Floodlight, Black, 90°, Non-Dim, 3000K
- ZRN100-3K-90-G ZORIN 100W Floodlight, Grey, 90°, Non-Dim, 3000K
- ZRN100-3K-100x60-B ZORIN 100W Floodlight, Black, 100x60°, Non-Dim, 3000K
- ZRN100-4K-90-B ZORIN 100W Floodlight, Black, 90°, Non-Dim, 4000K
- ZRN100-4K-90-G ZORIN 100W Floodlight, Grey, 90°, Non-Dim, 4000K
- ZRN100-4K-100x60-B ZORIN 100W Floodlight, Black, 100x60°, Non-Dim, 4000K
- ZRN100-4K-60-B ZORIN 100W Floodlight, Black, 60°, Non-Dim, 4000K
