CREST 24W
Square UGR<19 Panel Light 600x600
The CREST 24W LED is a high performing 600x600 Panel Light designed with a honeycomb diffuser which perfects the balance between light distribution, low glare, and visual appeal. CREST range are the ideal alternative to T8 fluorescent troffers and compare well with current T5 technology. They are used widely in a range of applications across Australia.
Verified by Techlume Australia on 12/07/2023
- Material Specifications
- MaterialAluminium Edgefold Back Sheet
- FinishWhite
- Dimensions595mm (L) x 595mm (W) x 10mm (D)
- Ingress ProtectionIP44
- AccessoriesSurface Mount Kits, Plaster Recessed Kits, Suspension Kits
- Weight3kg
- Warranty5 Year Warranty
- Electrical Specifications
- Power SupplyNon-Dim Driver
- OptionsDALI Available
- System Watts24.4W
- Input Voltage240V
- Connection MethodAustralian 2-Pin Plug & 1.2m Lead
- Operating Temperature (Ta)-20°C to +45°C
- Optic Specifications
- OpticsPMMA LGP
- Light Source4 Sides Edge-lit
- Delivered Lumens3,094lm
- Efficacy127 lm/W
- CRIRa 82
- UGR< 19
- Reported L70 (Hours)> 54,000 Hrs
Variations
- LC7214 CREST 24W Anti-Glare Panel Light 600x600, 100°, Non-Dim, 3000K
- LC7215 CREST 24W Anti-Glare Panel Light 600x600, 100°, Non-Dim, 4000K, 3,094lm
- LC7215D CREST 24W Anti-Glare Panel Light 600x600, 100°, DALI, 4000K, 3,094lm
Resources
- Data Sheet
-
LC7215
