LINX 11W
Linear Downlight Fixed
The LINX 11W Linear Recessed Downlight is an ultra-compact LED marvel. Experience unparalleled glare control with its lens and reflector fusion. Boasting a five module, linear light design and high CRI, it radiates commercial-quality brilliance. Choose between 24 or 40° beam angles to suit your needs. The secondary reflector is available in black, white, silver, and gold options. With a five year warranty, illuminate your space with confidence and elegance.
Verified by Techlume Australia on 09/03/2023
- Material Specifications
- MaterialHigh Grade Aluminium
- ColourWhite / Black Insert Options
- Ingress ProtectionIP40
- Dimensions152mm(L) x 45mm(W) x 60mm(D)
- Cutout144mm x 37mm
- Warranty5 Year Replacement
- Electrical Specifications
- Power SupplyActec 13W Driver 700mA, Phase Dim
- System Watts12.5W - 12.7W
- Connection MethodAustralian 2-Pin Plug & 1.0m Lead
- Input Voltage240V
- Optic Specifications
- Light SourceOsram 11W SMD LED
- Delivered Lumens987lm - 1053lm
- Efficacy>78lm/W
- Beam Angle24°/ 40°
- CRI>90Ra
- Colour DeviationSDCM ≤ 3
- UGR<19
- Reported L70 (Hours)> 54,000 Hrs
Variations
- LC4470 LINX 11W Linear Fixed Downlight, White w. Black Insert, 40°, Phase Dim, 3000K, 987lm
- LC4470B LINX 11W Linear Fixed Downlight, Black w. Black Insert, 40°, Phase Dim, 3000K, 987lm
- LC4470W LINX 11W Linear Fixed Downlight, White w. White Insert, 40°, Phase Dim, 3000K, 987lm
- LC4471 LINX 11W Linear Fixed Downlight, White w. Black Insert, 40°, Phase Dim, 4000K, 1053lm
- LC4471B LINX 11W Linear Fixed Downlight, Black w. Black Insert, 40°, Phase Dim, 4000K, 1053lm
- LC4471W LINX 11W Linear Fixed Downlight, White w. White Insert, 40°, Phase Dim, 4000K, 1053lm
Resources
- Data Sheet
-
LC4470
-
LC4470B
-
LC4471
