EXODUS BOXTER-C 2W
Wide Base Ceiling Exit Light
Synthium LED Surface Mounted Exit Light c/w Synthium Battery. This LED Exit light is presented in a traditional rectangular profile with a large 'PushConnect' mounting base to give installers the ultimate in simplicity, flexibility and versatility.
The wide base allows installers to easily run conduit, hide access cable and conceal existing defects on a previous installation, thus reducing unforeseen and undesirable site-related challenges.
Comes with all variations of the Running Man pictogram. C0-D10, C90-D8
- Material Specifications
- MaterialFlame-Retardant Polycarbonate
- MountingSurface Mounted - Ceiling
- Dimensions355mm(L) x 65mm(W) x 210mm(H)
- Weight1.5Kg
- Ingress ProtectionIP20
- Warranty5 Year Replacement
- Electrical Specifications
- Input Voltage240V; 50Hz
- Mode of OperationMaintained
- Battery & Charger SystemLithium Battery w. Intelligent 3-stage charger and battery management
- Operating Temperature (Ta)1°C - 40°C
- Protectionovercharge, low voltage disconnect, overcurrent, short circuit
- Connection MethodLarge Terminal Block, 20mm² Cable Entry
- Emergency Duration>120 Minutes
- Testing FacilityManual Test Switch
- IndicatorsBattery Charge Green LED
- Optic Specifications
- Light SourceHigh output LED Strip
- LED Wattage2W (Standby)
- AS2293 ClassificationC0-D10, C90-D8
- Rated Lifetime (L70B20)50,000 Hrs
Variations
- EXS-BOXC BOXSTER-C 2W Ceiling Wide Base Exit - 24m, maint.
