Recessed Exit Light

  • Material Specifications
  • MaterialFlame - Retardant Polycarbonate
  • ApplicationRecessed - Plaster Ceilings
  • Dimensions457mm(L) x 100mm(W) x 200mm(H)
  • Cutout430mm x 75mm cutout
  • Weight1.5Kg
  • Ingress ProtectionIP20
  • Warranty5 Year Replacement
  • Electrical Specifications
  • Mode of OperationMaintained
  • Battery & Charger SystemSynthium Battery w. Intelligent 3-stage charger and battery management
  • Operating Temperature (Ta)1°C - 40°C
  • ProtectionOvercharge, Low Voltage Disconnect, overcurrent, Short Circuit
  • Connection MethodComplete with Australian Plug + 1.2m Lead
  • Emergency Duration> 120 Minutes
  • Testing FacilityManual Test Switch
  • IndicatorsBattery Charger Green LED
  • Optic Specifications
  • LED Wattage4W (Standby)
  • Light SourceHigh Output LED Strip
  • AS2293 ClassificationC0-D6.3, C90-E3.2
  • EXS-BLADE BLADE 4W Recessed Exit Light - 24m, maint., White
  • EXS-BLADE-B BLADE 4W Recessed Exit Light - 24m, maint., Black
  • EXS-BLADE-BG BLADE 4W Recessed Exit Light - 24m, maint., Black w. White Decals
