EXODUS BLADE 4W
Recessed Exit Light
Exodus LED Recessed Mounted Blade Exit Light c/w Synthium Battery. The EXODUS Blade is a sleek and aesthetically pleasing recessed lithium exit light that provides a touch of class and elegance to enhance the look of any premium interior space.
Its ease of installation and stylish Running Man pictogram positions this fitting as the leading edge in the industry. Suited for apartments, public buildings, offices and retail outlets. Includes all variations of Running Man pictogram. C0-D6.3, C90-E3.2
- Material Specifications
- MaterialFlame - Retardant Polycarbonate
- ApplicationRecessed - Plaster Ceilings
- Dimensions457mm(L) x 100mm(W) x 200mm(H)
- Cutout430mm x 75mm cutout
- Weight1.5Kg
- Ingress ProtectionIP20
- Warranty5 Year Replacement
- Electrical Specifications
- Mode of OperationMaintained
- Battery & Charger SystemSynthium Battery w. Intelligent 3-stage charger and battery management
- Operating Temperature (Ta)1°C - 40°C
- ProtectionOvercharge, Low Voltage Disconnect, overcurrent, Short Circuit
- Connection MethodComplete with Australian Plug + 1.2m Lead
- Emergency Duration> 120 Minutes
- Testing FacilityManual Test Switch
- IndicatorsBattery Charger Green LED
- Optic Specifications
- LED Wattage4W (Standby)
- Light SourceHigh Output LED Strip
- AS2293 ClassificationC0-D6.3, C90-E3.2
Variations
- EXS-BLADE BLADE 4W Recessed Exit Light - 24m, maint., White
- EXS-BLADE-B BLADE 4W Recessed Exit Light - 24m, maint., Black
- EXS-BLADE-BG BLADE 4W Recessed Exit Light - 24m, maint., Black w. White Decals
- EXS-BLADE-ST BLADE 4W Recessed Exit Light - 24m, maint. c/w Self Test, White
