EXODUS PRIME 2W
Surface Mount Exit Light
Synthium LED Surface Mounted Exit Light complete with Synthium Battery. The EXODUS Prime is a low maintenance, wall or ceiling mountable exit light solution with all variations of the running man pictogram which offers many years of reliable, succinct and efficient Exit Lighting.
Using a simple slide and connect installation, its robust design allows it to be used in a wide variety of indoor applications, ranging from offices to retail stores, cafes and public spaces. C0-D3.2, C90-E2.5
- Material Specifications
- MaterialFlame-Retardant Polycarbonate
- MountingSurface Mounted - Wall or Ceiling
- Dimensions355mm(L) x 65mm(W) x 210mm(H)
- Weight1.5Kg
- Ingress ProtectionIP20
- Warranty5 Year Replacement
- Electrical Specifications
- Input Voltage240V; 50Hz
- Mode of OperationMaintained
- Battery & Charger SystemLithium Battery w. Intelligent 3-stage charger and battery management
- Operating Temperature (Ta)1°C - 40°C
- ProtectionOvercharge, low voltage disconnect, overcurrent, short circuit
- Connection MethodLarge Terminal Block, 20mm² Cable Entry
- Emergency Duration>120 Minutes
- Testing FacilityManual Test Switch
- IndicatorsBattery Charge Green LED
- Optic Specifications
- Light SourceHigh output LED Strip
- LED Wattage2W (Standby)
- AS2293 ClassificationC0-D3.2, C90-E2.5
Variations
- EXS-PRIME PRIME 2W Slide'n'Connect Slimline Exit - 24m, maint., White
