HAWKE 1500W
Asymmetric Sports Light
The HAWKE Floodlights are designed for flexibility in high output situations. The HAWKE 1500W Asymmetric Sports Light is suitable for mounting heights of up to 30 metres. Designed with different beam angles for use in sports grounds and arenas. The robust construction with a high lumen output enables optimum light spread for high light requirements. The updated design is more compact, for less wind force, and an improved bracket design.
- Material Specifications
- MaterialDie-Cast Aluminium Housing
- FinishAkzoNobel Powder Coat
- ColourDusty Grey (RAL7037)
- Dimensions568mm (W) x 953mm (H) x 271mm (D)
- Windage0.08m² at 0° tilt
- Ingress ProtectionIP66
- Impact RatingIK10
- Weight35.8kg (including drivers)
- Weight28.8kg (without drivers)
- Warranty5 Year Replacement
- Electrical Specifications
- Power Supply1pcs Inventronics Driver NES-1K8T210BC
- Input Voltage240V (5 amps)
- Max Distance From Power Supply200m
- Connection MethodDrivers can be remoted mounted
- Optic Specifications
- Light SourceSeoul 3535 LED
- Delivered Lumens212,200 - 231,000lm
- Calculated L70 (Hours)155,000 Hrs
- Calculated L80 (Hours)97,000 Hrs
- Calculated L90 (Hours)46,000 Hrs
Variations
- LC7801-40x15 HAWKE 1500W Floodlight, Grey, 40x15°, Non-Dim, 4000K
- LC7801-100x17 HAWKE 1500W Floodlight, Grey, 100x17°, Non-Dim, 4000K
- LC7801V-100x60 HAWKE 1500W Floodlight, Grey, 100x60°, Non-Dim, 4000K
- LC7801-130x25 HAWKE 1500W Floodlight, Grey, 130x25°, Non-Dim, 4000K
