CADE 40W
1200mm Slimline Ceiling Batten
CADE LED Ceiling Battens are an awesome new LED solution to replace standard fluorescent battens. Designed to be surface mounted. Very slim aesthetic design. Offering a low power consumption, and high lumen efficiency, the CADE Ceiling Light is the perfect light fitting for functional high-use areas. Available in a tri-colour version (3000K, 4000K, 5700K) for ultimate versatility and 20W and 40W options.
- Material Specifications
- Material6063 Aluminum housing + PC cover + PC end caps
- FinishWhite Powdercoat
- Dimensions80mm (W) x 35mm (H) x 1190mm (L)
- Ingress ProtectionIP44
- Impact RatingIK05
- Warranty5 Year Replacement
- Electrical Specifications
- Power SupplyIntegral, Non-Dimmable, 260mA
- Connection Method750mm cable with Wago terminals
- Operating Temperature (Ta)-20°C to +45°C
- Input Voltage240V
- Optic Specifications
- Light SourceEpistar SMD x 200pcs
- OpticsFrosted Diffuser
- Delivered Lumens3150lm
- Beam Angle150°
- CRI> 82Ra
- Reported L70 (Hours)> 40,000 Hrs
- LC2388 CADE 40W Surface Mount Batten, 1190mm, White, 150°, Non-Dim, Tri-Colour
