1200mm Slimline Ceiling Batten

  • Material Specifications
  • Material6063 Aluminum housing + PC cover + PC end caps
  • FinishWhite Powdercoat
  • Dimensions80mm (W) x 35mm (H) x 1190mm (L)
  • Ingress ProtectionIP44
  • Impact RatingIK05
  • Warranty5 Year Replacement
  • Electrical Specifications
  • Power SupplyIntegral, Non-Dimmable, 260mA
  • Connection Method750mm cable with Wago terminals
  • Operating Temperature (Ta)-20°C to +45°C
  • Input Voltage240V
  • Optic Specifications
  • Light SourceEpistar SMD x 200pcs
  • OpticsFrosted Diffuser
  • Delivered Lumens3150lm
  • Beam Angle150°
  • CRI> 82Ra
  • Reported L70 (Hours)> 40,000 Hrs
  • LC2388 CADE 40W Surface Mount Batten, 1190mm, White, 150°, Non-Dim, Tri-Colour
